Recycled carbon fiber reduces costs by 40% compared to virgin carbon fiber, benefiting environmental protection and lowering carbon emissions.
Recycled carbon fiber reduces costs by 40% compared to virgin carbon fiber, benefiting environmental protection and lowering carbon emissions.
Applications of green recycled chopped carbon fiber：
Plastic reinforcement: Nylon (PA), epoxy (EP), polypropylene (PP), polycarbonate (PC), phenolic (PF), etc.
Construction: Carbon fiber-reinforced cement, conductive coatings, anti-static flooring.
Electrical and thermal fields: Conductive paper, heating panels, conductive surface felts, needled felts.
Shielding materials: Smoke shielding, curtain walls.
Thermal insulation: Carbon fiber-reinforced refractory bricks, ceramics.
New energy: Fuel cell electrodes, structural components for new energy vehicles.
Drones: Propeller blades, fuselage structures.
Robotics: Robotic arms, support components.
Product Types：
| Model |
CF length mm |
Sizing Type |
Sizing ratio % |
Bulk density g/l |
Recommended matrix | |
| Resin | Others | |||||
| DQL- PU | 3—6 |
PU based multi- component formula |
2.0-5.0 Customizable |
360~460 | PA66、PA6 | POM、ABS、PBT、PC |
| DQL- PP | 3—6 |
PP based multi- component formula |
2.0-5.0 Customizable |
360~460 | PP | PE、POE |
| DQL- PC | 3—6 |
EP based multi- component formula |
2.0-5.0 Customizable |
360~460 | PC、EP | PBT、ABS、PA、POM、PPE、PF |
| DQL- PA | 3—6 |
PA, EP based multi- component formula |
2.0-5.0 Customizable |
360~460 | PA、PPS | PC、PBT、ABS |
Product Performance Reference：
|
Matrix Resin/CF |
CF Ratio wt.% |
Density g/cm3 |
Tensile Strength MPa |
Tensile Modulus MPa |
Tensile Elongation % |
Flexural Strength MPa |
Flexural Modulus MPa |
Charpy Impact Strength-Notched KJ/m2 |
|
PA66/CF (DQL-PA) |
0 | 1.12 | 78 | 3100 | 35.00 | 72 | 2500 | 3 |
| 20 | 1.22 | 190 | 14500 | 2.00 | 282 | 12400 | 15 | |
| 30 | 1.26 | 208 | 23800 | 2.20 | 300 | 17300 | 18 | |
|
PC/CF (DQL-PC) |
0 | 1.30 | 75 | 2300 | 115.00 | 92 | 2350 | 73 |
| 20 | 1.27 | 155 | 14000 | 1.80 | 255 | 13000 | 13 | |
| 30 | 1.30 | 176 | 20000 | 2.20 | 275 | 19000 | 15 | |
|
PP/CF (DQL-PP) |
0 | 0.90 | 33 | 1550 | 135.00 | 45 | 1650 | 15 |
| 20 | 1.00 | 88 | 8450 | 2.00 | 130 | 7500 | 15 | |
| 30 | 1.05 | 105 | 11500 | 2.20 | 145 | 10700 | 18 |
